Gravity table are capable of separating dry granular particles of uniform size which differ in specific gravity. They are employed throughout the seed industry to remove light undesirable seed from a wide variety of seed crops. Proper use of a Sanli Gravity Separator will improve the overall quality of any seed lot.

5XZ series gravity table have a rectangular deck so that the product travels a longer distance resulting in cleaner separation of light and heavy particles. The product flows over the vibrating deck in which pressurized air is forced through causing the material to stratify according to its specific weight. The heavier particles travel to the higher level and the lighter particles travel to the lower level of the deck.

Better maintenance access and improved serviceability. And the automated controls promote precision, repeatability and ease of use

It may be used to separate and standardize sunflower seed, coffee, peanuts, corn, peas, paddy, wheat, sesame and other food grains.

Technical parameters

Model		5XZ-5A	5XZ-5B
Max-feeding Capacity	Wheat seed	4000-5000 Kg/h	4000-6000 Kg/h
	Maize	3500-4500 Kg/h	3500-5500 Kg/h
	Bean &Peas	3000-4000 Kg/h	3000-5000 Kg/h
	Rice seed	2400-3000 Kg/h	2400-3500 Kg/h
	Sunflower seed	1000-1500 Kg/h	1000-2000 Kg/h
Overall Size (L×W×H)		3870×1720×1700mm	3870×1845×1700mm
Screen size		3150×1380 mm
Weight		1390 Kg	1420 Kg
Power supply		380V / 50Hz / 3-Phase
Total power		9.0 kW	9.2 kW
Selection rate		≥98%	≥98%
Side opening		Without	with
Remarks		Can with Cyclone duster

Note: The capacities may vary depending on seed condition, moisture content, seed varieties, types and volumes of contaminants to be separated and percentage of foreign material acceptable in the final product.
