● With speed switch to start or stop the stirring at any time.
● Timing function (0-9999min), time adjustable under artificial requirement. Audible and visual alarm equipped.

● Double sensor: outer PT100 sensor to control liquid temperature precisely, inner K model sensor to control hot plate temperature.

● One key to shift inside and outside sensor easily and precisely.

● Large display can indicate temperature, rotational speed and timing at the same time.

Technical Parameters

Model		SH-4A	SH-4B	SH-4	SH-4C	SH-Ⅱ-4C
Mode		Heating	Stirring	Heating+Stirring	Digital+Heating+Stirring
Function	Max.Volume (Ml)	5000	5000	5000	5000	5000
	Speed (r.p.m)	－	200～2000
	Working time	Continuous
	Minimum revolution (R.P.M)	－	200	200	200	200
	Max.Temp (℃)	380	－	380	350	350
Structure	Exterior	Iron plate welding, surface spraying
	Heating plate	Ceramic coated
	Driving mode	－	Motor
	Motor power (W)	－	20	20	20	20
	Heating power (kW)	0.6	－	0.6	0.6	0.6
	Stir bar	No	PTFE
Controller	Continuous operation	Yes
	Setting mode	Scale			Digital
	Speed display mode	Scale			Digital
	Timer	No				Yes
	Operation function	No				Yes
	Sensor	No			PT100	PT100
Specification	Exterior size (W×L×H)	320×190×125 mm
	Packing size (W×L×H)	390×240×230 mm
	Plate size	190×190 mm
	Plate load	10 Kg
	Power supply	110V or 220V / 50/60Hz
	NW/GW	5/6 Kg
