■ Intelligence operation surface,overall upgrade (10-inch ) capacitive touch screen proved the zooming and sliding function,easy test and operation,multiple sorting modes make you operating easier.

■ Original creative high frequency solenoid valve,with the national patent certification,operating reached 12 billion times makes the solenoid valve is not a quick-wear part anymore;respond rapidly,lower air-consumption.

■ Overall new chute design,specoal technology chute makes material transfer more steady and output increased 20%-30%,meanwhile, we also could provide plate-type and slot-type for meeting the various demands.

■ Adjustable ligh source technology,the overall upgrade LED light source could adjust the outpit power of ligh source according to those different materials,ensure the accurate obtaining of materials’s information;LED lighting system with radiating function makes it in longer using,lower energy consumption and better performance.

Technology parameters

Name	HF1	HF2	HF4
Model	6SXZ-21(CCD)	/	6SXZ-168(CCD)
Capacity(T/H)	≥0.1	≥0.3	2-5
Voltage(V)	AC220V/50HZ	AC220V/50HZ	AC220V/50HZ
POWER(KW)	<2.0	<2.0	<2.2
Weight(KG)	530	/	1000
Dimension(LWH/MM)	100016502100	/	217016151825
Air Consumption	0.9 m³/min	1.8m³/min	1.8 m³/min
Air pressure	0.6-0.8mpa	0.6-0.8mpa	0.6-0.8mpa
Air compressor power	7.5kw	7.5kw	11kw*2
Air tank	500L	600L	1000L
Cooling Model	wind cooling	wind cooling	wind cooling
Mini Resolution( mm²)	0.03	0.03	0.03
